1kw 5 Kw off Grid Hybrid Home PV Inverter Battery Bank Product Energy Solar Panel Solar Power System

Basic Info.

Model NO.	SMSH-1KW
Specification	Normal, CE, RoHS, ISO 9001
System Capacity	1-15kw Available
MPPT Voltage Range	300-1000V
Output Frequency	50Hz/60Hz
Solar Module Efficiency	17%
Accessories	All Included
Waterproof Degree	IP67
Waveform	Thd<2%
Solar Panel Rack	Optional
PV Combiner Box	16A
Warranty (Year)	5years
Protection	Polarity Reverse, Voltage Surge, Over Current
Roof Required Areas	1m2 for 150W
Inverter	Pure Sine Wave Output
Voltage	24V
Solar Panel	Mono
Transport Package	Carton
Trademark	SunMaster
Origin	Zhejiang, China
HS Code	8502390000
Production Capacity	50000pieces/Year

Packaging & Delivery

Package Size 110.00cm * 50.00cm * 20.00cm Package Gross Weight 3200.000kg

Product Description

Connecting Diagram

Configuration List

Item	Certification	Description	Q'ty	Warranty
Solar panel	TUV / IEC / EC	Mono or Poly	8 pcs	20 years
Inverter	CGC / CQC / VDE	One (MPPT) tracking/ one phase 220V, 2000W/ SM-SH2000	1 set	5 years
Distribution box (Optional)	CE	Lighting Protection. Air switch, Fusegar, knife switch,	1 set	5 years
Mounting system	CE	Slant roof bracket/ Cement Ground bracket/ Soil ground bracket	1set	10 years
PV cable	TUV/ UL	DC port PV1-F	20m	10 years
		AC port YJV-3$4mm2	5m	10 year

Solar Panel

Type	MONO		POLY
Power class	280W	335W	270W	320W
Open Circuit Voltage (Voc)	38.1	9.36	38.1	45.8
Short Circuit Voltage (Isc)	9.27	46	9.23	9.15
Max power Voltage (Vmp)	8.84	8.76	31.1	37.2
Max Power Current (Imp)	8.84	8.76	8.69	8.61
Efficiency	≥17.1%	≥17.2%	≥16.5%	≥16.4%
Dimension (mm)	1650x991x35	1960x991x35	1650x991x35	1960x991x35z
Weight (kg)	18±5%	22.5±5%	18±5%	22.5±5%

Solar Inverter

Ambient temperature range	-25~+60ºC(>45ºC deloading)
Relative humidity	0~95%
Max operating altitude	4000m (>3000m derating)
Protection degree	IP65
Topology	Transformerless
Night power consumption (W)	<1
Cooiong method	Natural convection
Noise emision (dB)	<25
Display	LCD
Warranty (Year)	5/10/15/20/25 (Optional) Years

Solar Controller

Rated Charge current(A)		40A
Rated DC voltage(V)		24/48 automatic identification
Solar input Max voltage(V)		42/84
Battery	Over charge protective voltage(V)	28.6/57.2
Battery	Over charge recover voltage(V)	27.4/54.8
Battery	Constant charge voltage(V)	27/54
Battery	Over discharge alarm voltage(V)	20/40
Environment Humidity and temperature		0-90% No condense,55ºC
Protective Functions		Protection against anti-charge at night,battery over charge, over discharge protection,Joint-reversed of solar modules

PV Combiner Box

Components	Parameter	Function
Circuit breaker (Air switch)	16A	When the current of the protected circuit exceeds the specified value, the circuit breaker will automatically break off to protect the whole circuit.
Fusegear	16A	When the current of the protected circuit exceeds the specified value, fusegear will break off automatically
Surge protective device (SPD)	UC:420V lmax:20KA; In: 10KAUp≤1.8KV	Photovoltaic lightning protection device
One phase self dual over voltage protection device	Working range 220V,50Hz, over voltage protectionUvo=270V±5V Under voltage protection Uoe= 170±5V	When the circuit voltage is highet or lower, it will shut down automatically. when the voltage reaches standard level, it will recover automatically.
Knife switch	/	automatic/ by hand

Conductor	Tinned Fine Re Copper Strand, according to VDE0295/IEC60228. Class 5
Insulation	Polyolefin Copolymer electron-beam coss-linked
Sheath Jacket	Polyolefin Copolymer electron-beam coss-linked
Nominal Voltage	Uo/U=600V/1000VAC, 1000V/1800VDC
Test Voltage	6500V, 50Hz, 5Min
Temperature Rating	-40°C-125°C ,More than 25 Years (TUV)
Fire Performance	IEC 60332-1
Smoke Emission	IEC61034, EN 50286-2
Low Fire Load	DIN 51 900
Certification	TUV 2PFG 1169/08 2007 PV1--F

Mounging System

The wind capacity of such mounting system can reach (40m/s, 32.5kg/ square meters, level 13), snow load capacity can reach 70kg/ square eters

The whole system has strong safety performance.

Can be customized based on customer's cactual situation

The mounting system can be desingned with best solution based on slope roof, flat ground and soil ground

---
