Tier1 China Manufacturer Jinko Solar Panels 530W 535W 540W 545W 550W Mono
Jinko Solar Mono 530w -550w Solar Panel182mm *91mm Solar Cells144 half Cells Solar PanelELECTRICAL DATA A Grade Material
Basic Info.
Model NO. | JKM550M-72HL4 |
Material | Monocrystalline Silicon |
Panel Efficiency | 21.33% |
Backsheet | Tpt Material |
Weight | 28kg |
Front Glass | 3.2mm Tempered Glass |
Cable | 4mm^2 300mm PV Cable |
Frame | Anodized Aluminium Alloy |
Service | OEM Avaliable |
Type | Perc |
Glass | 3.2mm Tempered Low Iron |
Junction Box | IP 68 Rated |
Solar Cell | A Grade |
Transport Package | 31PCS in a Carton |
Specification | 2274*1134*35mm |
Trademark | JinKo Solar |
Origin | China |
HS Code | 85414020 |
Production Capacity | 2gwyears |
Product Description
Jinko Solar Mono 530w -550w Solar Panel182mm *91mm Solar Cells144 half Cells Solar PanelELECTRICAL DATA
SPECIFICATIONS (STC) | |||||
Module Type | JKM530M-72HL4-V | JKM535M-72HL4-V | JKM540M-72HL4-V | JKM545M-72HL4-V | JKM550M-72HL4-V |
Maximum Power (Pmax) | 530Wp | 535Wp | 540Wp | 545Wp | 550Wp |
Maximum Power Voltage (Vmp) | 40.56V | 40.63V | 40.70V | 40.80V | 40.90V |
Maximum Power Current (Imp) | 13.07A | 13.17A | 13.27A | 13.36A | 13.45A |
Open-circuit Voltage (Voc) | 49.26V | 49.34V | 49.42V | 49.52V | 49.62V |
Short-circuit Current (Isc) | 13.71A | 13.79A | 13.85A | 13.94A | 14.03A |
Module Efficiency STC (%) | 20.55% | 20.75% | 20.94% | 21.13% | 21.33% |
Operating Temperature(ºC) | -40ºC~+85ºC | ||||
Maximum system voltage | 1000/1500VDC (IEC) | ||||
Maximum series fuse rating | 25A | ||||
Power tolerance | 0~+3% | ||||
Temperature coefficients of Pmax | -0.30%/ºC | ||||
Temperature coefficients of Voc | -0.25%/ºC | ||||
Temperature coefficients of Isc | 0.046%/ºC | ||||
Nominal operating cell temperature (NOCT) | 45±2ºC |
Production process
Project CasesFactory
Delivery Methods
FAQ.
1. What's your payment terms and conditions?T/T, Letter of Credit, Paypal, Western Union etc. on FOB, CIF , CFR , DDU , DDP etc.2. Can we print our own sticker ?Yes, OEM and ODM is our key advantage !3. What are the advantages of your company ?In the past years, we mostly do OEM for Tier 1 . From 2017, we are launching our own brands , with good quality and competitiveoffer . Contact
